Project Description

Abrasive Jumbo Roll Slitting & Cut To Length 2 in 1 Machine

This machine is designed as a machine which combine abrasive jumbo roll slitter and abrasive cut to length machine 2 in 1.
It would finish the abrasive material slitting and length cutting at same time.
Converter can get a required size at one time. It doesn’t need to slit abrasive jumbo rolls into narrow rolls, then take narrow rolls from jumbo roll slitter and put on a cut to length machine.
Save time and save money.

TECHNICAL INFO

Max working width of this machine: 1400/ 1650mm
Max abrasive roll diameter: 1m
Max weight of jumbo roll: 1T
Minimum slitting width: 50mm
5 sets of slitting knife sets (5 sets is standard one. If you need more, we can customize for you)
Equipped with heavy duty slitting knife set
Automatic edge position correcting device
Automatic length counting and quantity setting on screen
With a removable touching screen for easy operation
Cutting length range: 100-4000mm
Cutting angle: 45-90 degree
Cutting method: press cutting
Pressing method: Gas-liquid pressurization
Wave & straight cutting both available

BASIC PARAMETERS

Weight: 1800KG
Voltage: 3 phase, 380V
Power: 3.5KW
